Sheet metal screws 4.2x13 raised countersunk head DIN 7983, sz, 100 pcs.

- The antenna is designed for mounting in inherently stable plastic assemblies.
- The operating voltage is supplied to the antenna via a separate supply line
- The voltage supply must be connected to a fused circuit
- Can be used with 4724.05 (broadcast distributor for AM/FM and DAB+ frequency division)
- The voltage lead of the broadcasting distributor is not connected
- Cable type: RG58
- Services: AM/FM, DAB
- Cable length: 2.5 m
- Connectors: FAKRA(f) Z

Additional information:
- Mounting: Adhesive/screw mounting
- Additional info: Broadcast antenna
- Category/Special feature: powerful active and floating dipole antenna

Dimensions:
- Width: 63 mm
- Height: 10 mm
- Length: 75 mm
- Weight: 0.183 kg

Note:
Drivers of many camper vans complain about poor VHF/FM reception. This active antenna, which can be easily installed under plastic parts, provides a remedy.
With the specified splitter, the antenna can also be used for DAB+ reception.

We recommend the following accessories:
- ATTB_4724_05: Passive splitter with FAKRA/DIN/SMB connectors
- 8479 (Fakra plug - DIN plug, 5 m)
- If the radio has an ISO input, the Dietz adapter 8302 is also required.

Original article number: 5010.02

*************************************************************************************************
Product safety information:
Brand: ATTB
Manufacturer: ATTB Antennentechnik Bad Blankenburg GmbH, Gewerbegebiet 2, 07407 Rudolstadt, info@attb.de
*************************************************************************************************

Broadcast distributor for vehicle or house interiors with the following functions and features:
- Distribution of AM/FM and DAB+ frequency ranges
- Phantom power supply for an external antenna or radio amplifier
- Simple and quick mounting
- Cable type: RG 174
- Services: AM/FM, DAB, DAB+
- Connectors: SMB(f), FAKRA(m) Z, DIN 41585(m)

Additional information:
- Mounting: adhesive/screw mounting
- Additional info: Crossover
- Category/special feature: passive crossover for active single-cable solution

*************************************************************************************************
Product safety information:
Brand: ATTB
Manufacturer: ATTB Antennentechnik Bad Blankenburg GmbH, Gewerbegebiet 2, 07407 Rudolstadt, info@attb.de
*************************************************************************************************
