DAB/FM Splitter - Crossover without amplifier FAKRA/DIN/SMB

Professional antenna for optimum reception of VHF/DAB+ and GPS/GLONASS for front installation on vans. Antenna with the following features:

- Flat angle of only 25 degrees.
- Antenna with optimised rod, length approx. 41.5 cm, in 16 V design.
- DAB+ reception 174-237 MHz & 1452-1492 MHz
- VHF/FM reception 87-108 MHz
- GPS/GLONASS 1575.42 MHz
- 12 V external power supply (no phantom power possible)
- Low installation depth approx. 16 mm
- Gain: FM: 15 dBi
- Gain: DAB+: 18dBi
- Gain: GPS+: 29dBi
- Power supply: 12 volts, 100 mA
- Temperature range (-40 degrees to + 85 degrees Celsius)
- Impedance: 50 Ohm
- Cable to antenna:
- Cable: RG 174, FM 300 mm, Fakra plug, white, code B
- Cable: RG 174, DAB+ 300 mm, Fakra plug, grey, code G
- Cable: RG 174, GPS/GLONASS,+ 300 mm, fakra plug, blue, code C

Note: This antenna is delivered without cable!

Recommended LOWLOSS extension cable:

For FM and DAB+:

UNI-2L350:
UNI LOWLOSS set with different connectors for FM. With this cable set, 99% of the car radios on the market can be connected with our antennas. The set consists of 2 LowLoss antenna cables with Fakra colour coding for VHF and DAB+.

- VHF lowloss cable Fakra socket - Fakra socket B, white
- DAB+ lowloss cable Fakra socket - SMB socket 90 degrees, Fakra G, grey
Adapter for FM:
- Adapter with lowloss fakra cable - DIN plug
- Adapter with lowloss fakra cable - ISO plug

For GPS/GLONASS:

UNI-3L350:
GPS connection cable set. Universal set for 99% of all devices!

Completely blue colour coding according to fakra standard to avoid signal confusion.

- 3.5 metre RG174 cable fakra socket - fakra socket, fakra C, blue
- Adapter RG174 Fakra plug - GT5 socket for GPS connection of e.g. Alpine, Kenwood and Clarion devices.
- Adapter RG174 Fakra plug - GT16 socket for the GPS connection of e.g. Pioneer devices.

Other variants:



*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Dietz
Hersteller/Manufacturer: Audiotechnik Dietz Vertriebs-GmbH, Maybachstr. 10, 67269 Grünstadt,
www.dietz.biz, verkauf@dietz.biz
*************************************************************************************************
FM/DAB+:
UNI-2L500: Set with 5 m cable length
UNI-2L750: Set with 7.5 m cable length
UNI-2L1000: Set with 10.0 m cable length

GPS/GLONASS:
UNI-3L500: Set with 5 m cable length
UNI-3L750: Set with 7.5 m cable length
UNI-3L1000: Set with 10.0 m cable length

Low-loss cables are the cables with the best electrical properties for the loss-free transmission of antenna signals. Our Lowloss cable series has the best conductivity values and thus the lowest cable resistance. They are achieved by using tinned strands for the inner conductor (7*d=0.25mm), for the shield (42*d=0.11mm) and an additional aluminium foil between the PE dielectric and the shield. Only high-quality Fakra plugs and sockets from Rosenberger are used. They have an excellent finish and fit due to a special punching and bending technology by Rosenberger (Fakra-SF).

Technical data of the low loss cable:

Characteristic impedance: 50 Ohm
d capacitance: 95pF/m
Extended POLYTHEN insulation 2.00 mm
Aluminium foil shielding and additional tinned copper braiding
Outer diameter: 3.6 mm


*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Dietz
Hersteller/Manufacturer: Audiotechnik Dietz Vertriebs-GmbH, Maybachstr. 10, 67269 Grünstadt,
www.dietz.biz, verkauf@dietz.biz
*************************************************************************************************

Active radio distributor for the vehicle or house interior with the following functions and features:
- Distribution of analogue radio and DAB, DAB+ frequency ranges
- Improvement of the reception quality of passive radio antennas
- Simple and quick mounting
- Cable type: RG 174
- Services: AM/FM, DAB, DAB+
- Connectors: SMB(f), DIN 41585(f), DIN 41585(m)

Note:
- The product is intended for typical roof/fender antennas.
- Do not use with integrated glass or active roof antennas

Additional information:
- Mounting: adhesive/screw mounting
- Additional info: Crossover
- Category/Special feature: Active crossover for passive single-cable solution

Also works with active FM/UKW antennas if the antenna itself does not filter the frequency band. With a phantom antenna, a phantom adapter must be inserted between the splitter and the antenna connection, e.g. 8551, as any phantom voltage from the radio is not passed through.

The best results are achieved when the splitter is combined with a passive FM/UKW/DAB antenna: - 16 V antenna: ATTB_2116_01 - Flex antenna with adjustable rod from 10-115 degrees: ATTB_3940_01 - Shark/shark antenna: ATTB_3759_01 These antennas always have a piece of cable 40cm with a Fakra socket. You can then use a possibly existing Fakra cable or bring the signal into the dashboard with the extension cable Dietz: 8479 (Fakra plug - DIN plug, length 5 metres). Connect the splitter there. If the radio has an ISO antenna connection for FM, you will also need the adapter, Dietz 8300.

Original article number: 4726.01

*************************************************************************************************
Product safety information:
Brand: ATTB
Manufacturer: ATTB Antennentechnik Bad Blankenburg GmbH, Gewerbegebiet 2, 07407 Rudolstadt, info@attb.de
*************************************************************************************************

Broadcast distributor for vehicle or house interiors with the following functions and features:
- Distribution of AM/FM and DAB, DAB+ frequency ranges
- Phantom power supply for an external antenna or radio amplifier
- Simple and quick mounting
- Cable type: RG 174
- Services: AM/FM, DAB, DAB+
- Connectors: SMB(f), DIN 41585(f), DIN 41585(m)

Additional information:
- Mounting: adhesive/screw mounting
- Additional info: Crossover
- Category/special feature: passive crossover for active single-cable solution

*************************************************************************************************
Product safety information:
Brand: ATTB
Manufacturer: ATTB Antennentechnik Bad Blankenburg GmbH, Gewerbegebiet 2, 07407 Rudolstadt, info@attb.de
*************************************************************************************************
