Calearo/ MTA VHF/FM motorized antenna, black rod

Generates an additional DAB/DAB+ signal from an FM/VHF antenna.
Connections to the radio:
FM/UKW: 150 Ohm DIN plug
DAB/DAB+: SMB socket
Connector to antenna: 150 Ohm DIN socket


Also works with active FM/UKW antennas if the antenna itself does not filter the frequency band.
The following adapter cables are included in the delivery:
8524 Fakra socket DIN plug
8514 Fakra socket DIN socket
8526 Fakra socket SMB socket

Technical data:
Frequencies/amplification:

AM=0.15-1.71MHz, 25 dB +/-1
FM=87,5-108MHz, 13,5 dB +/-1
III Band=174-240 MHz, 21 dB +/-1
L BAND=1452-1492 MHz, 14 dB +/-1

Current consumption: 110 mA
Impedance: 50 Ohm
Replacement for: 7562030

*************************************************************************************************
Product safety information:
Brand: Calearo
Manufacturer: MTA S.p.A., V.le dell'Industria, 12 - 26845 Codogno (LO) – ITALY, info@mta.it
*************************************************************************************************

Technical Datas:
2-Way-System
Max. Power: 90 Watt
Power: 45 Watt RMS
SPL: 91 dB/1 Watt/1 Meter
Frequency-Range: 95-22.000 Hz
Impedanz: 4 Ohm
Water resistant
Universal mounting brackets
Cable: 2 * 0,75 mm2; 1,75 m

Size:
Without holder: 110*110*101 (H*B*T)
With holder: 130*137*101 (H*B*T)

For:
marine, KFZ, truck, tractor, construction machinery, mobile home, camping, satellite speakers, wall and ceiling speakers, atmos speaker, auro speaker



*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Dietz
Hersteller/Manufacturer: Audiotechnik Dietz Vertriebs-GmbH, Maybachstr. 10, 67269 Grünstadt,
www.dietz.biz, verkauf@dietz.biz
*************************************************************************************************

Integrated amplifier
- Blue LED-Light (switchable)
- Separate power supply 9- 16 Volt
- Max. power consumption < 80 mA
- AM 0.15-6.2 MHz
- FM 76-108 MHz, +6dB, Noise figure < 6dB
- DAB 174-240 MHz, +18dB, Noise fig. < 4dB
- Connector: SMB (DAB) + DIN (FM/ AM)
- Cable: 2.85 m
- Operation temperature: -30°C - +95°C
- Compatible with all Blaupunkt Car Radios
- DAB/ FM antenna can also be used individually
- Non- destructive assembling, for nonheated/non-coated windscreens
- Antenna lenght 450mm (2 pcs.)
- Amplifier ? 50mm x 15mm
- Successor of 7 617 495 142 001

*************************************************************************************************
Product safety information:
Brand: Blaupunkt
Manufacturer: Evo-Sales GmbH, Hastenbecker Weg 33, 31785 Hameln, ticket@bpautomotive.de
*************************************************************************************************

Services

- AM/FM
- Active antenna with integrated blue switchable illumintation ring

Installation place:
- Universal on-glass antenna for adhesive attachment to the rear or front windscreen

Highlight

- New attractive design "High-Tec-Look"
- Illumination indicates amplifier function
- Outstanding channel seperation on AM/FM by overload-proof cirquit

Customer benefits

- Simple "no-hole" mounting, no rusting
- Ideal antenna for leasing cars
- Optimum reception quality
- Maintenance free an vandal-proof
- Illumination can be switched on/off

*************************************************************************************************
Product safety information:
Brand: Blaupunkt
Manufacturer: Evo-Sales GmbH, Hastenbecker Weg 33, 31785 Hameln, ticket@bpautomotive.de
*************************************************************************************************
