According to our tests, the A10 antenna is currently the best antenna for optimum radio reception in camper vans. The electronics, the antenna radiator and the antenna supports are perfectly matched to each other. For vehicles where height is not an issue, we always recommend the 41 cm antenna radiator. You will be thrilled!
Delivery contents:
Antenna A10
Antenna support 3, stainless steel 400*400*1 mm, white powder coated RAL 9003
Central hole d= 20 mm
Lowloss cable 10 m, Fakra socket - Fakra socket, for VHF
Adapter 1: Fakra plug - DIN plug
Adapter 2: Fakra plug - ISO plug
Lowloss cable 10 m, Fakra socket - SMB socket , for DAB+
Roof antenna with the following features:
- 16V antenna with long rod, length approx. 41 cm
- DAB+ reception, active and low noise in BAND 3
- VHF/FM/AM reception, active and low-noise
- 12 V power supply via external cable 0.75 mm2 (phantom powering not possible)
- Low installation depth (approx. 15 mm)
- Gain: FM: 9 dB
- Gain: DAB+: 14 dB
- Power supply: 12 volts, 30mA
- Cable: RG 174, FM 300 mm, Fakra plug, white, code B
- Cable: RG 174, DAB+ 300 mm, Fakra plug, grey, code G
Low-loss cables are the cables with the best electrical properties for the loss-free transmission of antenna signals. Our lowloss cable series has the best conductivity values and therefore the lowest cable resistance. They are achieved by using tinned strands for the inner conductor (7*d=0.25mm), for the shield (42*d=0.11mm) and an additional aluminium foil between the PE dielectric and the shield. Only high-quality Fakra plugs and sockets from Rosenberger are used. They have an excellent finish and fit due to a special punch-bend technology of the Rosenberger company(Fakra-SF).
Technical data:
Characteristic impedance: 50 Ohm
Capacity: 95pF/m
Extended POLYTHEN insulation 2.00 mm
Aluminium foil shielding and additional tinned copper braiding
Outer diameter: 3.6 mm
Note: This set replaces the previous sets:
A1T3L1000UNI
