Roof antenna with the following functions and features:
- DAB+ reception, active and low-noise in the ranges B III, L-band passive.
- Radio reception, active and low-noise for AM/FM
- 12 V power supply for the amplifiers either via inner conductor of the cable connections (only one connection recommended) or DIN plug-in sleeve
- Active GNSS antenna (phantom power)
- Low-noise antenna rod
- Low installation depth (15 mm)
- Low installation effort, only one mounting hole for 3 functions
- Interchangeable with conventional flex antennas
- Cable type: RG 174
- Services: GLONASS, AM/FM, GPS, DAB+
- Connectors: FAKRA(m) G, FAKRA(m) B, FAKRA(m) C

Especially suitable for:
- Analogue and digital broadcasting
- Navigation systems
- Fleet management

Additional information:
- Mounting: Roof mounting
- Additional information: Kombiflex roof antenna
- Category/Special feature: active antenna with separate signal routing, GPS diagnostic function (only with 3761_06)

Dimensions:
- Width: 65 mm
- Height: 270 mm
- Length: 104 mm
- Weight: 0.153 kg

Suitable replacement antenna: ATTB_4626_11

The antenna is delivered with the following cable set:

LowLoss cable set no. 3, consisting of LowLoss antenna cable with Fakra colour coding for ATTB antennas with FM and DAB+ and RG174 cable for GPS content:
- 5 metre lowloss cable fakra socket - DIN plug, fakra B, beige
- 5 metre lowloss cable Fakra socket - SMB socket 90 degrees, Fakra G, grey
- 5 metre RG174 cable fakra socket - fakra socket, fakra C, blue
- Adapter Fakra male - GT5 female for GPS connection of e.g. Alpine, Kenwood and Clarion devices.

Low loss cables are the cables with the best electrical properties for the loss-free transmission of antenna signals. Our Lowloss cable series has the best conductivity values and therefore the lowest cable resistance. They are achieved by using tinned strands for the inner conductor (7*d=0.25mm), for the shield (42*d=0.11mm) and an additional aluminium foil between the PE dielectric and the shield. Only high-quality Fakra plugs and sockets from Rosenberger are used. They have an excellent workmanship and fit due to a special punching-bending technology of Rosenberger(Fakra-SF).

Original article number of the antenna: 3761.06

*************************************************************************************************
Product safety information:
Brand: ATTB
Manufacturer: ATTB Antennentechnik Bad Blankenburg GmbH, Gewerbegebiet 2, 07407 Rudolstadt, info@attb.de
*************************************************************************************************
