The CXNup 2B dual-battery charge controller offers exceptional features in its class:
In addition to PWM charge control with temperature compensation and an LCD, the CXNup 2B controller is equipped with extensive control, programming and safety functions. The battery's state of charge is permanently displayed via a bar graph, as are the energy flows to the batteries. When installed in a camper van, the CXNup 2B keeps the starter battery fully charged and provides flexible presets for the batteries. The solar charge controller also has acoustic warning functions.
Functional description
- The charge controller protects the battery from overcharging by the solar generator and deep discharge by the consumers. Charging is carried out by means of a multi-stage charging characteristic which is also temperature-compensated in order to achieve optimum battery charging.
- The charge controller automatically detects the battery voltage and sets itself to 12 V or 24 V operation.
- The charge controller has a user-friendly LCD, adjustable parameters and a range of protective functions.
For the following battery types:
- Lead acid batteries, (GEL, AGM, hydrofluoric acid batteries),
- LiFePO4
Technical data:
20 A charging current,
12/24 VDC,
4 mA self-consumption,
LCD, IP20, screw terminal up to 16 mm²,
data loffer (MXI/CXLink)
Product Weight: 0.17 kg Dimensions: 103 x 101 x 32 mm (LxWxH)
Contact us for advice!
*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Phaesun
Hersteller/Manufacturer: Phaesun GmbH, Brühlweg 9, 87700 Memmingen, info@phaesun.com
*************************************************************************************************
