ISO-ISO (power & LS) 1:1 extension cable for OPEL, 18 cm

Generates an additional DAB/DAB+ signal from an FM/VHF antenna.
Connections to the radio:
Fakra plug
DAB/DAB+: Fakra plug
Connection to the antenna: Fakra plug

Also works with active FM/UKW antennas if the antenna itself does not filter the frequency band. In the case of a phantom antenna, a phantom adapter must be inserted between the splitter and the antenna connection, e.g. 8551.
For adaptation to radios with ISO and DIN connectors we recommend the complete kits
41121, 41122 and 41123 or the use of the following adapters:

(not included in delivery):
8524 Fakra socket DIN plug
8514 Fakra socket DIN socket
8525 Fakra socket ISO plug
8555 Fakra socket ISO socket
8526 Fakra socket SMB socket
8527 Fakra socket SMA plug

8529 Fakra socket to Fakra socket

Technical data:
Frequencies/amplification:

AM=0.15-1.71MHz, 25 dB +/-1
FM=87,5-108MHz, 13,5 dB +/-1
III Band=174-240 MHz, 21 dB +/-1
L BAND=1452-1492 MHz, 14 dB +/-1

Current consumption: 110 mA
Impedance: 50 Ohm

Also known under Art. No. 7561004

*************************************************************************************************
Product safety information:
Brand: Calearo
Manufacturer: MTA S.p.A., V.le dell'Industria, 12 - 26845 Codogno (LO) – ITALY, info@mta.it
*************************************************************************************************

Roof antenna with the following functions and features:
- DAB+ reception, active and low-noise in the ranges B III, L-band passive.
- Radio reception, active and low-noise for AM/FM
- 12 V power supply for the amplifiers either via inner conductor of the cable connections (only one connection recommended) or DIN plug-in sleeve
- Active GNSS antenna (phantom power)
- Low-noise antenna rod
- Low installation depth (15 mm)
- Low installation effort, only one mounting hole for 3 functions
- Interchangeable with conventional flex antennas
- Cable type: RG 174
- Services: GLONASS, AM/FM, GPS, DAB+
- Connectors: FAKRA(m) G, FAKRA(m) B, FAKRA(m) C

Especially suitable for:
- Analogue and digital broadcasting
- Navigation systems
- Fleet management

Additional information:
- Mounting: Roof mounting
- Additional information: Kombiflex roof antenna
- Category/Special feature: active antenna with separate signal routing, GPS diagnostic function (only with 3761_06)

Dimensions:
- Width: 65 mm
- Height: 270 mm
- Length: 104 mm
- Weight: 0.153 kg

Suitable replacement antenna: ATTB_4626_11

Suitable extension cable:

8482: Fakra socket to SMB socket
8483: Fakra socket to DIN plug
8489: Fakra socket to Raku 2 socket
8481: Fakra socket to Fakra socket plus adapter for GPS, e.g. 8641
(Fakra plug to GT 16 socket for Pioneer) or 8610 (Fakra plug to devices with GT5, such as Kenwood, Clarion or Alpine)

Original article number: 3761.06

*************************************************************************************************
Product safety information:
Brand: ATTB
Manufacturer: ATTB Antennentechnik Bad Blankenburg GmbH, Gewerbegebiet 2, 07407 Rudolstadt, info@attb.de
*************************************************************************************************
