Facia adaptor MERCEDES A-, B-class, Sprinter (W906), VW Crafter

Generates an additional DAB/DAB+ signal from a passive FM/VHF antenna. Amplification FM/UKW and DAB+ 20dB each Connections to the radio: DIN plug SMB socket Connection to antenna: DIN socket Also works with active FM/UKW antennas if the antenna itself does not filter the frequency band. With a phantom antenna, a phantom adapter must be inserted between the splitter and the antenna connection, e.g. 8551, as any phantom voltage from the radio is not passed through. The best results are achieved when the splitter is combined with a passive FM/UKW/DAB antenna: - 16 V antenna: ATTB_2116_01 - Flex antenna with adjustable rod from 10-115 degrees: ATTB_3940_01 - Shark/shark antenna: ATTB_3759_01 These antennas always have a piece of cable 40cm with a Fakra socket. You can then use a possibly existing Fakra cable or bring the signal into the dashboard with the extension cable Dietz: 8479 (Fakra plug - DIN plug, length 5 metres). Connect the splitter there. If the radio has an ISO antenna connection for FM, you will also need the adapter, Dietz 8300.


*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Dietz
Hersteller/Manufacturer: Audiotechnik Dietz Vertriebs-GmbH, Maybachstr. 10, 67269 Grünstadt,
www.dietz.biz, verkauf@dietz.biz
*************************************************************************************************
