CD player via USB interface - Adaptive

Coming soon
Sales start at the beginning of 2024

Radio
- High-END CODEM IV world tuner
- FM, AM, DAB, DAB+ tuner with radio text/ DSL, traffic prioritisation, alphabetical DAB station list, automatic station memory function, service following, playback functions (band scan)

Media player
- USB (2x). MP2. MP3, WMA, FLAC, M4A (AAC), APE, WAV support
- Playback functions, various playback modes Playback modes
- Apple iPod support

Bluetooth
- Telephony via int. or ext. microphone
- Audio streaming with track display
- Voice assistant access (e.g. Siri, Google, Alexa)
- Wake-up on call
- Phone book access

Sound presets
- Sound presets
- Loudness
- 4-channel preamp output + sub-out
- 4x 50 watts

General information
- Multi colour LCD (7 colours)
- DIM function
- Night design when switched off (buttons)
- Favourite button for one source
- Permanent memory
- Short installation depth
- IR remote control compatible with old RC-10SWC (steering wheel remote control)

*************************************************************************************************
Product safety information:
Brand: Blaupunkt
Manufacturer: Evo-Sales GmbH, Hastenbecker Weg 33, 31785 Hameln, ticket@bpautomotive.de
*************************************************************************************************

Youngtimer / classic car radio with a 90s look. Old design - new technology!

Radio
- High-end CODEM IV high-end world tuner
- FM (RDS), AM tuner
- Built-in DAB+ tuner

Data carrier
- USB, MMC, SD, SDHC (up to 32 GB)

Media player
- Audio from USB/SDHC
- Audio formats MP3, WMA

Bluetooth
- Bluetooth module built-in (HFP, PBAP, A2DP, SPP, AVRCP)
- Twin-Connect
- Phone book access
- Integrated + external microphone
- Navigation Audio Mix

Inputs / Outputs
- 1x front USB
- 1x rear USB
- 1x front aux-in
- 1x front SDHC card reader
- Steering wheel remote control (programmable)

Equalizer / Amplifier
- 3-band semi-parametric equaliser
- Sound Presets (Rock, Pop, Classic)
- X-Bass
- 4-channel preamplifier (4V)
- Separate sub-out
- 4 x 50 Watt Max. Power

General
- Vario Color (illumination of buttons & display in 5 colours)
- Fixed front panel
- Permanent memory
- IR remote control included
- DAB+ window antenna included
- External BT microphone included

Subject to technical changes.

*************************************************************************************************
Product safety information:
Brand: Blaupunkt
Manufacturer: Evo-Sales GmbH, Hastenbecker Weg 33, 31785 Hameln, ticket@bpautomotive.de
*************************************************************************************************

Professional antenna for optimum reception of VHF/DAB+ and GPS/GLONASS for front installation on vans. Antenna with the following features:

-flat angle of only 25 degrees.
- Antenna with optimised rod, length approx. 41.5 cm, in 16 V design.
- DAB+ reception 174-237 MHz & 1452-1492 MHz
- VHF/FM reception 87-108 MHz
- 12 V external power supply (no phantom powering possible)
- Low installation depth approx. 16 mm
- Gain: FM: 7 dB
- Gain: DAB+: 12dB
- Power supply: 12 volts, 100 mA
- Temperature range (-40 degrees to + 85 degrees Celsius)
- Impedance: 50 Ohm
- Cable to antenna:
- Cable: RG 174, FM 300 mm, Fakra plug, white, code B
- Cable: RG 174, DAB+ 300 mm, Fakra plug, grey, code G
- Cable: RG 174, GPS/GLONASS,+ 300 mm, fakra plug, blue, code C

Note: This antenna is delivered with the following cable sets in 3.5 m length!

Recommended LOWLOSS extension cables:

For FM and DAB+:

UNI-2L350:
UNI LOWLOSS set with different connectors for FM. With this cable set, 99% of the car radios on the market can be connected with our antennas. The set consists of 2 LowLoss antenna cables with Fakra colour coding for VHF and DAB+.

- VHF lowloss cable Fakra socket - Fakra socket B, white
- DAB+ lowloss cable Fakra socket - SMB socket 90 degrees, Fakra G, grey
Adapter for FM:
- Adapter with lowloss fakra cable - DIN plug
- Adapter with lowloss fakra cable - ISO plug

For GPS/GLONASS:

UNI-3L350:
GPS connection cable set. Universal set for 99% of all devices!

Completely blue colour coding according to fakra standard to avoid signal confusion.

- 3.5 metre RG174 cable fakra socket - fakra socket, fakra C, blue
- Adapter RG174 Fakra plug - GT5 socket for GPS connection of e.g. Alpine, Kenwood and Clarion devices.
- Adapter RG174 Fakra plug - GT16 socket for the GPS connection of e.g. Pioneer devices.

Low-loss cables are the cables with the best electrical properties for the loss-free transmission of antenna signals. Our lowloss cable series has the best conductivity values and therefore the lowest cable resistance. They are achieved by using tinned strands for the inner conductor (7*d=0.25mm), for the shield (42*d=0.11mm) and an additional aluminium foil between the PE dielectric and the shield. Only high-quality Fakra plugs and sockets from Rosenberger are used. They have an excellent finish and fit due to a special punching and bending technology by Rosenberger (Fakra-SF).

Technical data of the low loss cable:

Characteristic impedance: 50 Ohm
d capacitance: 95pF/m
Extended POLYTHEN insulation 2.00 mm
Aluminium foil shielding and additional tinned copper braiding
Outer diameter: 3.6 mm


*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Dietz
Hersteller/Manufacturer: Audiotechnik Dietz Vertriebs-GmbH, Maybachstr. 10, 67269 Grünstadt,
www.dietz.biz, verkauf@dietz.biz
*************************************************************************************************
