Butt connector, PU=100, red, industrial quality

Dietz MiniDAB 66600 – DAB+ for every FM radio

The easy way to upgrade to digital radio

With the Dietz MiniDAB, any conventional FM radio becomes DAB+-compatible in no time. The compact DAB+ radio receiver can be easily integrated into existing audio systems and ensures clear digital radio reception – without replacing the radio or complicated modifications.

How the MiniDAB works

The Dietz MiniDAB can be flexibly operated with various antenna solutions:
- with the Dietz DAB window antenna 41104
- with any other Dietz or ATTB DAB antenna
- or – in many vehicles – via the Dietz active splitter 2726_01

The audio signal is fed in directly via the radio's FM antenna input. The existing FM antenna is automatically switched off, and the audio signal from the Dietz MiniDAB is fed in via the preset frequency of 87.7 MHz. This allows DAB+ to be played back simply through your existing FM radio.

All important station information, such as station name, title, and artist, is conveniently displayed on the radio screen via the RDS signal – clear and easy to read.

Incredibly easy to use

Control is conveniently managed via a remote control:

- On/Off button
- Forward and Previous buttons
- 5 preset buttons for your favorite stations

Station scanning and switching are fast and reliable – for maximum listening comfort without any waiting time.

Your advantages at a glance

- DAB+ retrofit for almost any FM radio
- Flexible antenna connection possible with Dietz components
- Clean audio feed via 87.7 MHz
- Station and track display via RDS
- Easy operation via remote control
- When the radio is restarted, the last listened-to station automatically resumes playing
- Simple settings menu for rescanning, alternative frequencies, reset, and software update
- Compact design & high-quality technology

Scope of delivery:

- MiniDAB receiver with power cable
- Remote control with batteries and steering wheel mount
- DIN/ISO/Fakra antenna adapter set for any car radio with DIN, ISO, or single Fakra input
In detail:
1 DIN/ISO adapter
1 adapter ISO/DIN
1 cable 0.75m Fakra female to DIN male
1 cable 0.75m Fakra female to DIN female
1 extension cable 0.75m Fakra female to Fakra male
1 extension cable 0.75m Fakra female to Fakra female

- Operating instructions

Recommended accessories

- Dietz disc antenna DZ_41101 or
- Dietz 16V rod antenna DZ_2113_01 or
- ATTB 16V rod antenna ATTB_2118_01 or
- Dietz active splitter DZ_2726_01
- Dietz premium splitter series DZ_2736_xx

Technical data:

Operating voltage: 10-16 volts
Power consumption in operating mode: < 150mA
Standby current in sleep mode: < 7mA
Antenna switching voltage: yes, via external 12V cable, no phantom power
Update option via USB port
Temperature range: -20 to +70 degrees Celsius

*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Dietz
Hersteller/Manufacturer: Audiotechnik Dietz Vertriebs-GmbH, Maybachstr. 10, 67269 Grünstadt,
www.dietz.biz, verkauf@dietz.biz
*************************************************************************************************
