Highest quality and reliability "Made in Germany".
The ATTB 3761.01 roof antenna is an antenna developed and manufactured by Antennentechnik Bad Blankenburg for retrofitting vehicles. ATTB specialises in radio-based networking solutions for various industries and applications. With its own research, development and production, ATTB has stood for the highest quality and reliability "Made in Germany" since 1919.
We drive connectivity: networking without compromise
The ATTB Kombiflex roof antenna 3761_01 establishes reliable, high-performance radio connections in the fields of broadcasting and navigation and is suitable for mobile outdoor use. It undergoes the most stringent testing processes, is manufactured in Germany from high-quality components and offers first-class transmission or reception performance - even under the most difficult conditions.
Frequency bands and communication services
The ATTB 3761_01 multifunction antenna covers several frequency bands and thus communication services. These include AM, FM, DAB+ and GPS.
- In the broadcasting range, AM (0.15 -16 MHz), FM (87.5 - 108 MHz), DAB+ (B III: 174 - 240 MHz) and DAB+ (L band: 1452 - 1492 MHz) can be received.
- The ATTB 3761_01 roof antenna is also designed to receive GNSS navigation signals (GPS: 1575.42 MHz).
Special features and characteristics
- Active and low-noise radio reception (AM, FM)
- Active and low-noise DAB reception in the B III ranges
- passive DAB reception in the L-band ranges
- Active and low-noise radio and GPS reception for LMK/UKW
- Active antenna with separate signal routing
- Active GNSS antenna (phantom power supply)
- 12 V power supply for the amplifier either via DIN plug-in sleeve or via inner conductor of the cable connections (only one connection recommended)
- Low-noise antenna rod
- Low installation depth (15 mm)
- Low installation effort (only one mounting hole for 3 functions)
- Exchangeable with conventional flex antennas
Dimensions:
- Width: 65 mm
- Height: 270 mm
- Length: 104 mm
- Weight: 0.172 kg
Matching replacement radiator: ATTB_4626_11
The antenna is delivered with the following cable set:
LowLoss cable set no. 4, consisting of LowLoss antenna cable with Fakra colour coding for ATTB antennas with FM and DAB+ and RG174 cable for GPS content:
- 7.5 metre lowloss cable fakra socket - DIN plug, fakra B, beige
- 7.5 metre lowloss cable Fakra socket - SMB socket 90 degrees, Fakra G, grey
- 7.5 metre RG174 cable fakra socket - fakra socket, fakra C, blue
- Adapter Fakra male - GT5 female for GPS connection of e.g. Alpine, Kenwood and Clarion devices.
Low loss cables are the cables with the best electrical properties for the loss-free transmission of antenna signals. Our Lowloss cable series has the best conductivity values and therefore the lowest cable resistance. They are achieved by using tinned strands for the inner conductor (7*d=0.25mm), for the shield (42*d=0.11mm) and an additional aluminium foil between the PE dielectric and the shield. Only high-quality Fakra plugs and sockets from Rosenberger are used. They have an excellent workmanship and fit due to a special punching-bending technology of Rosenberger(Fakra-SF).
Original article number of the antenna: 3761.01
*************************************************************************************************
