With this cable set, 99% of the car radios on the market can be connected with our antennas from ATTB and A1, A2, A3 and AS1 series.

LowLoss cable set no. 9, consisting of 2 LowLoss antenna cables with Fakra colour coding for ATTB antennas with FM and DAB+.
Contents:
- 3.5 metre lowloss cable fakra socket - fakra socket, beige
- 3.5 metre lowloss cable fakra socket - SMB socket 90 degrees, fakra G, grey

Adapter for VHF:
- Adapter with lowloss fakra cable - DIN plug
- Adapter with lowloss fakra cable - ISO plug

Low loss cables are the cables with the best electrical properties for the loss-free transmission of antenna signals. Our Lowloss cable series has the best conductivity values and therefore the lowest cable resistance. They are achieved by using tinned strands for the inner conductor (7*d=0.25mm), for the shield (42*d=0.11mm) and an additional aluminium foil between the PE dielectric and the shield. Only high-quality Fakra plugs and sockets from Rosenberger are used. They have an excellent finish and fit due to a special punch-bend technology of the Rosenberger company(Fakra-SF).

Technical data:

Length: 5 metres
Characteristic impedance: 50 Ohm
Capacity: 95pF/m
Extended POLYTHEN insulation 2.00 mm
Aluminium foil shielding and additional tinned copper braiding
Outer diameter: 3.6 mm

Ideal to connect active antennas of the company Antenne Bad Blankenburg with the digital car radio.

For example:
ATTB_2118_01, original number: 2118.01
ATTB_2121_01, original number: 2121.01
ATTB_3761_01, Original number: 3761.01
ATTB_3761_06, Original number: 3761.06
ATTB_3766_01, Original number: 3766.01
ATTB_3775_01, Original number: 3775.01
ATTB_3777_01, Original number: 3777.01
ATTB_3785_01, Original number: 3785.01
ATTB_3792_01, Original number: 3792.01
ATTB_3793_01, Original number: 3793.01
ATTB_3796_03, Original number: 3796.03
ATTB_4578_01, Original number: 4578.01



*************************************************************************************************
Angaben zur Produktsicherheit/GPSR:
Marke/Trademark: Dietz
Hersteller/Manufacturer: Audiotechnik Dietz Vertriebs-GmbH, Maybachstr. 10, 67269 Grünstadt,
www.dietz.biz, verkauf@dietz.biz
*************************************************************************************************

Low-loss cables (...little loss cables) are the cables with the best electrical properties for the loss-free transmission of antenna signals. Our Lowloss cable series has best conductance values and therefore lowest cable resistances. They are achieved by using tinned strands for the inner conductor (7*d=0.25mm), for the shield (42*d=0.11mm) and an additional aluminium foil between the PE dielectric and the shield. Only high-quality Fakra plugs and sockets from Rosenberger are used. They have an excellent finish and fit due to a special punch-bending technology from Rosenberger(Fakra-SF).

Technical data:

Length: 3 meters
characteristic impedance: 50 Ohm
Capacity: 95pF/m
Extended POLYTHEN insulation 2.00 mm
Aluminium foil shielding and additional tinned copper braid
Outer diameter: 3.6 mm

Specially designed for loss-free transmission of FM/UKW signals from antenna Blankenburgantennen or all other antennas that have a Fakra plug for FM/UKW.


*************************************************************************************************
